Absolute Distance

Absolute Distance measures the direct distance between selected sketch references. Use it when the design intent depends on true separation rather than only horizontal or vertical offset.

Select a line to dimension its direct length, or select two points or references to dimension the true distance between them. Double-click an existing absolute distance label to edit its value.
